Product Description
- Fits Models: GTO
- Fits Years: 04-06
- Fits Transmissions: Turbo 400, 2004R
- We recommend Energy Suspension Short GM 1 5/8" transmission mount. The GMTM-S is sold separately.
- This crossmember is manufactured from high quality steel and MIG welded.
The G Force Patented Transmission Crossmember
Performance Engineered from Start to Finish
Performance
Engineered
Engineered and independently tested to withstand the rigors of the track, each crossmember exceeds the demands of even the most challenging roads.
Easy Installation.
It’s Foolproof!
Our unique bolt-to-frame design eliminates cutting and welding. The distinctive double-hump accommodates true dual exhaust. A G Force crossmember is guaranteed to be a perfect fit.
SHOPTALK
See the G Force Crossmember Overview for more info.
The RCV4-400 is installed with the G Force label facing the rear of the vehicle and the slots on top facing the transmission mount.
Specific GTOs include:
2004 Pontiac GTO-5.7L V8 Base Coupe 2-door
2005 Pontiac GTO-6.0L V8 Base Coupe 2-door
2006 Pontiac GTO-6.0L V8 Base Coupe 2-door. See the G Force Crossmember Overview for more info.
This crossmember is installed with the G Force label facing the rear of the vehicle. However, another determining feature is the crossmember center tube which has a 1/2″ drain slot that is positioned on the bottom and on the passenger side next to the hump weldment.
This crossmember is installed so that the exhaust clearance humps are closed on the top and open on the bottom.
To use the provided 7/16″ hardware it is necessary to enlarge holes in your frame rails with a 1/2″ drill. If you choose to use the stock size 3/8″ hardware, it is strongly recommended to use new Grade #8 fasteners to compensate.
Discover more about the G Force Crossmember product line on these pages-
The RCV4-400 is installed with the G Force label facing the rear of the vehicle and the slots on top facing the transmission mount.
Specific GTOs include:
2004 Pontiac GTO-5.7L V8 Base Coupe 2-door
2005 Pontiac GTO-6.0L V8 Base Coupe 2-door
2006 Pontiac GTO-6.0L V8 Base Coupe 2-door. See the G Force Crossmember Overview for more info.
This crossmember is installed with the G Force label facing the rear of the vehicle. However, another determining feature is the crossmember center tube which has a 1/2″ drain slot that is positioned on the bottom and on the passenger side next to the hump weldment.
This crossmember is installed so that the exhaust clearance humps are closed on the top and open on the bottom.
To use the provided 7/16″ hardware it is necessary to enlarge holes in your frame rails with a 1/2″ drill. If you choose to use the stock size 3/8″ hardware, it is strongly recommended to use new Grade #8 fasteners to compensate.
Discover more about the G Force Crossmember product line on these pages-
Years
2004 | 2005 | 2006
Models
| Pontiac: | GTO |
Transmissions
Turbo 400 | 200R4
Specifications
Weight: 27 lbsShipping Dimensions: 18 × 12 × 3 In
Finish: Black Powder Coated
Mounting Hardware: Not Included
-
